XPAC-8000/XPAC-Atom

Chia sẻ

Thương hiệu: ICP DAS Loại: Đang cập nhật

Tình trạng: Còn hàng

Mã sản phẩm: XPAC-8000/XPAC-Atom

XPAC-8000/XPAC-Atom (Windows Embedded Standard 2009/WinCE 6.0 Based PAC)

CAM KẾT CỦA CHÚNG TÔI

Cam kết 100% chính hãng
Hoàn tiền 111% nếu hàng giả
Giao hàng nhanh chóng & an toàn
Hàng hóa đầy đủ CO, CQ
Hỗ trợ 24/7

Để được hỗ trợ. Hãy gọi: 0904251826

Khuyến mãi đặc biệt !!!

Áp dụng Phiếu quà tặng/ Mã giảm giá theo ngành hàng.
Miễn phí vận chuyển với đơn hàng từ 10.000.000đ

Mô tả sản phẩm

XPAC-8000/XPAC-Atom (Windows Embedded Standard 2009/WinCE 6.0 Based PAC)

	Will be available
	Available soon
	Will be phased out
	Phased out

Standard XP-8000/XP-8000-Atom (Windows Embedded Standard 2009 Inside) The controller supports following software development tools: 1. DLLs of I/O modules for VS.NET 2005/2008 2. OPC server for SCADA software
Model		OS	Pre-Installed Software	CPU	Flash	DDR SDRAM	VGA Resolution	Ethernet Port	RS-232/RS-485	I/O Slot
	XP-8041	WES2009	None	LX 800 500 MHz	4 GB	1 GB	1600 x 1200	2	5	0
	XP-8341								4	3
	XP-8741									7

	XP-8141-Atom	WES2009	None	Atom Z520 (1.33 GHz)	16 GB	1 GB	1600 x 1200	2	4	1
	XP-8341-Atom									3
	XP-8741-Atom									7

TOP

HOME

InduSoft Based XP-8000 (Windows Embedded Standard 2009 Inside)

InduSoft Web Studio is a powerful, integrated collection of automation tools that includes all the building blocks needed to develop modern Human Machine Interfaces (HMI), Supervisory Control and Data Acquisition (SCADA) systems, and embedded instrumentation and control applications. To run InduSoft on XP-8000 controller is as simple as you are running on PC.

To know more about InduSoft, please refer to web page.
http://www.icpdas.com/products/Software/InduSoft/indusoft.htm

To know and purchase InduSoft license, please refer to InduSoft Ordering Information page.
http://www.icpdas.com/products/Software/InduSoft/indusoft.htm#order

TOP

HOME

	Will be available
	Available soon
	Will be phased out
	Phased out

Standard XP-8000-CE6/XP-8000-Atom-CE6 (Windows CE6 R3 Core Inside) The controller supports following software development tools: 1. DLLs of I/O modules for VS.Net 2005/2008 2. DLLs of Modbus/RTU and Modbus/TCP for VS.Net 2005/2008 3. OPC server (Quicker)
Model		OS	Pre-Installed Software	CPU	Flash	DDR SDRAM	VGA Resolution	Ethernet Port	RS-232/RS-485	I/O Slot
	XP-8041-CE6	CE 6.0 R3 Core	None	AMD LX 800 500 MHz	4 GB	512 MB	1024 x 768 (or above)	2	5	0
	XP-8341-CE6								4	3
	XP-8741-CE6									7

	~~XP-8141-Atom-CE6~~	CE 6.0	None	Atom Z510 (1.10 GHz)	8 GB	512 MB	1024 x 768	2	4	1
	~~XP-8341-Atom-CE6~~									3
	~~XP-8741-Atom-CE6~~									7

TOP

HOME

Win-GRAF Standard XP-8000-CE6 (Windows CE6 R3 Core Inside) The controller fully supports all five of the IEC61131-3 standard PLC languages: 1. Ladder diagram, 2. Function block diagram, 3. Sequential function chart, 4. Structured text, 5. Instruction List. It supports Modbus protocol and can link to distributed I/O modules with Modbus or DCON protocol via the RS-232/485 or Ethernet.
Model		OS	Pre-Installed Software	CPU	Flash	DDR SDRAM	VGA Resolution	Ethernet Port	RS-232/RS-485	I/O Slot
	XP-8048-CE6	CE 6.0 R3 Core	Win-GRAF	AMD LX 800 500 MHz	4 GB	512 MB	1024 x 768 (or above)	2	5	0
	XP-8348-CE6								4	3
	XP-8748-CE6									7

TOP

HOME

ISaGRAF Standard XP-8000-CE6/XP-8000-Atom-CE6 (Windows CE6 R3 Core Inside) The controller fully supports all five of the IEC61131-3 standard PLC languages: 1. Ladder diagram, 2. Function block diagram, 3. Sequential function chart, 4. Structured text, 5. Instruction List plus flow chart. It supports Modbus protocol and can link to distributed I/O modules with Modbus or DCON protocol via the RS-232/485 or Ethernet.
Model		OS	Pre-Installed Software	CPU	Flash	DDR SDRAM	VGA Resolution	Ethernet Port	RS-232/RS-485	I/O Slot
	XP-8047-CE6	CE 6.0 R3 Core	ISaGRAF	AMD LX 800 500 MHz	4 GB	512 MB	1024 x 768 (or above)	2	5	0
	XP-8347-CE6								4	3
	XP-8747-CE6									7

	~~XP-8147-Atom-CE6~~	CE 6.0	ISaGRAF	Atom Z510 (1.10 GHz)	8 GB	512 MB	1024 x 768	2	2	1
	~~XP-8347-Atom-CE6~~									3
	~~XP-8747-Atom-CE6~~									7

TOP

HOME

InduSoft Standard XP-8000-CE6/XP-8000-Atom-CE6 (Windows CE6 R3 Core Inside) The controller can be used to develop following applications: 1. Human Machine Interfaces (HMI) 2. Supervisory Control and Data Acquisition System (SCADA) 3. Web server
Model		OS	Pre-Installed Software	CPU	Flash	DDR SDRAM	VGA Resolution	Ethernet Port	RS-232/RS-485	I/O Slot
	XP-8049-CE6	CE 6.0 R3 Core	InduSoft	AMD LX 800 500 MHz	4 GB	512 MB	1024 x 768 (or above)	2	5	0
	XP-8349-CE6								4	3
	XP-8749-CE6									7

	~~XP-8149-Atom-CE6~~	CE 6.0	InduSoft	Atom Z510 (1.10 GHz)	8 GB	512 MB	1024 x 768	2	4	1
	~~XP-8349-Atom-CE6~~									3
	~~XP-8749-Atom-CE6~~									7

TOP

HOME

ISaGRAF & InduSoft Based XP-8000-CE6 (Windows CE6 R3 Core Inside) The controller includes features of ISaGRAF and InduSoft.
Model		OS	Pre-Installed Software	CPU	Flash	DDR SDRAM	VGA Resolution	Ethernet Port	RS-232/RS-485	I/O Slot
	XP-8046-CE6	CE 6.0 R3 Core	Indusoft + ISaGRAF	AMD LX 800 500 MHz	4 GB	512 MB	1024 x 768 (or above)	2	5	0
	XP-8346-CE6								4	3
	XP-8746-CE6									7

	~~XP-8146-Atom-CE6~~	CE 6.0	Indusoft + ISaGRAF	Atom Z510 (1.10 GHz)	8 GB	512 MB	1024 x 768	2	4	1
	~~XP-8346-Atom-CE6~~									3
	~~XP-8746-Atom-CE6~~									7
