Miễn phí vận chuyển với đơn hàng từ 10.000.000đRemote I/O kết nối 16 kênh đầu ra số DO Cimon RC-YT16A
Remote I/O
Real-time control over distributed I/O.
Supports various I/O of 16 points and 32 points units.
Install up to 64 devices.
Save on installation and maintenance costs.
Easy system set-up with a convenient system, repair and maintenance configurations.
Simple programming for communication.
-Special program of dialog form.
-Auto-scan function through CICON.
Integration of CPU, power, I/O, communication function in one module provides a convenient all-in-one solution.
Checks communication condition of long distance module through monitor.
Built-in Auto Baud Rate function so that an extra settings for communication speed is unnecessary.
Supports various communication speed (10K/20K/50K/80K/100K/125K/250K/500K/1000Kbps).
Prevents noise from the communication line through insulation of communication diagnostic.
Built-in LED for diagnostic functions (Power, Module, Line condition).
Communication specifications
|
Item |
Standard |
|
|---|---|---|
|
Transmission standard |
Standard |
ISO11898 |
|
Interface |
CAN BUS |
|
|
Media accessory |
POLL |
|
|
Topology |
Bus |
|
|
Cable |
Twisted Pair Shielded Cable |
|
|
Comm. Distance |
1000 m (10 kbps) |
|
|
Max. number of node |
||
|
Maximum I/O data |
||
|
40 m (1000 kbps) |
||
|
Max. Number of Node |
63 stations |
|
|
Max. I/O Data |
8 byte |
|
I/O specifications
|
Item |
Input |
Mixed |
Output |
|||||
|---|---|---|---|---|---|---|---|---|
|
DC(Sink/Source) |
DC(Sink/Source) |
TR(Sink) |
TR(Sink) |
Relay |
||||
|
Model |
RC-XD32A |
RC-XD16A |
RC-XY32DT |
RC-YT32A |
RC-YT16A |
RC-YR16A |
||
|
Point |
32points |
16points |
16points |
16points |
32points |
16points |
16points |
|
|
Power |
DC24V |
|||||||
|
I/O voltage/current |
DC24V / 7mA |
DC24V / 7mA |
DC24V / 0.5A |
DC24V / 0.5A |
DC24V / 2A |
|||
|
Response |
Off → on |
3ms or less |
3ms or less |
2ms or less |
2ms or less |
10ms or less |
||
|
on → Off |
3ms or less |
3ms or less |
2ms or less |
2ms or less |
5ms or less |
|||
|
Common method |
16points / COM |
32points / COM |
16points / COM |
16points / COM |
||||
|
Current consumption |
300mA |
400mA |
350mA |
500mA |
||||
|
External connection type |
Terminal connector |
|||||||
|
Status signal |
Input ON : LED ON |
Input ON : LED ON |
Output ON : LED ON |
Output ON : LED ON |
Output ON : LED ON |
|||
|
Insulation |
Communication |
Photo-coupler between communication port and inner circuit |
||||||
|
I/O |
Photo-coupler between I/O and inner circuit |
|||||||
|
Inner circuit |
Sink/Source겸용 |
Sink/Source |
Sink |
Sink |
Sink/Source |
|||
