| Model Name | PEX-P8POR8i | PEX-P16POR16i | PCI-P16PO16U | PCI-P16POR16 |
| Digital Input | ||||
| Isolation Voltage | 2000 VDC (Photocouple) | 5000 Vrms (Photocouple) | ||
| Channels | 8 | 16 | ||
| Input Voltage | Logic 1: AC/DC 5 ~ 24 V (AC 50 ~ 1 kHz) Logic 0: AC/DC 0 ~ 1 V |
|||
| Input Impedance | 1.2 KΩ, 0.5 W | 1.2 KΩ, 1 W | ||
| Response Speed | Without Filter: 50 kHz (Typical) With Filter: 0.455 kHz(Typical) |
|||
| Relay Output | ||||
| Channels | 8 | 16 | ||
| Relay Type | PhotoMos Relay(Form A) | |||
| Contact Rating | Load Voltage: 300 V (AC peak or DC) Load Current: 130 mA |
|||
| Operate Time | 0.7 ms (typical) | |||
| Release Time | 0.05 ms (typical) | |||
| Insulation Resistance | 1000 MΩ @ 500 VDC | |||
| Electrical Endurance (Resistive load) | Long Life and No Spike | |||
| Special | ||||
| LED Indicators | Output status | |||
| General | ||||
| Bus Type | PCI-Express x1 | 3.3 V/5 V Universal PCI, 32-bit, 33 MHz | 5 V PCI, 32-bit, 33 MHz | |
| Data Bus | 16-bit | |||
| Card ID | Yes (4-bit) | |||
| I/O Connector | Female DB37 x 1 | Female DB37 x 1 40-pin box header x 1 |
||
| Dimensions (L x W x D) | 173 mm x 113 mm x 22 mm | 118 mm x 113 mm x 22 mm | 183 mm x 105 mm x 22 mm | |
| Power Consumption | 800 mA @ +5 V | |||
| Operating Temperature | 0 ~ 60 °C | |||
| Storage Temperature | -20 ~ 70 °C | |||
| Humidity | 5 ~ 85% RH, non-condensing | |||
