| Configuration Interface | ||
| COM Port | RS-232(3 wires) | |
| Connector | RJ-45 10 Pin | |
| HART Interface | ||
| HART Channel | 1 | |
| HART Interface | 2-pin screwed terminal block | |
| HART Device | 2-wired or 4-wired HART devices | |
| HART Topology | Point to Point | |
| HART Data | Only Digital Data | |
| HART Frame Type | Short and Long Frame | |
| Burst Mode | Supported | |
| Max. HART Device | 1 | |
| Loop Resistor | 250 Ω (Jumper selectable) | |
| Isolation | UL1577 Spec. | |
| Analog Output | ||
| Channel | 4 | |
| Current Range | 0/4~20mA, source or sink (The external voltage range for sink type is 5~30VDC) |
|
| Load | Source | ≦750 Ω |
| Sink | ≦1.1k Ω @30VDC | |
| Alarm (Relay) Output | ||
| Channel | 2 Form A (SPST-NO) / 2 Form C (SPST-NO/NC) | |
| Contact Rating | DC | 5A @ 24VDC |
| AC | 5A @ 250VAC (47~63Hz) | |
| Operate Time | 10ms (Max.) | |
| Release Time | 5ms (Max.) | |
| Insulation Resistance | 1000MΩ at 500VDC | |
| Endurance | Mechanical | 2 x 107 ops |
| Electrical | 1 x 105 ops | |
| Power | ||
| Power supply | Unregulated +10 ~ +30 VDC | |
| Protection | Power reverse polarity protection, Over-voltage brown-out protection | |
| Power Consumption | 3 W / 6 W (If choose source type current output) | |
| Mechanism | ||
| Installation | DIN-Rail | |
| Dimensions | 110 mm x 90 mm x 33 mm (W x L x H, without connector) | |
| Environment | ||
| Operating Temp. | -25 ℃ ~ +75 ℃ | |
| Storage Temp. | -30 ℃ ~ +80 ℃ | |
| Humidity | 5% ~ 95% RH, non-condensing | |
