F2816: FDD-LTE (4G) IP MODEM (FDD-LTE (4G) DTU) 2 cổng RS-232 + 1 cổng RS-485 + 1 AI + 2 DIO

Chia sẻ

Thương hiệu: Four-Faith Loại: Modem IP LTE(4G)

Tình trạng: Còn hàng

Mã sản phẩm: F2816

FDD-LTE (4G) IP MODEM (FDD-LTE (4G) DTU) 2 cổng RS-232 + 1 cổng RS-485 + 1 AI + 2 DIO

CAM KẾT CỦA CHÚNG TÔI

Cam kết 100% chính hãng
Hoàn tiền 111% nếu hàng giả
Giao hàng nhanh chóng & an toàn
Hàng hóa đầy đủ CO, CQ
Hỗ trợ 24/7

Để được hỗ trợ. Hãy gọi: 0904251826

Khuyến mãi đặc biệt !!!

Áp dụng Phiếu quà tặng/ Mã giảm giá theo ngành hàng.
Miễn phí vận chuyển với đơn hàng từ 10.000.000đ

Mô tả sản phẩm

F2816: FDD-LTE (4G) IP MODEM (FDD-LTE (4G) DTU) 2 cổng RS-232 + 1 cổng RS-485 + 1 AI + 2 DIO

Features

	Ultra-Low Power Consumption Using multi-level sleep and wake-up mode. The power consumption at mode of working, standby , and sleep [sleep consumption <5mA] are lower than similar products in the industry, show evident advantage in the situation when inconvenient to get powered.
	First Choice for Integration Terminal Data Transparent Transmission Four-Faith Data Transmission Terminal support APN transmission or Virtual VPDN transmission, fully guarantee the data transmission security and accuracy and avoid any information reveal.
	Fully Compatible with 4G/3G/2.5G Network All models fully compatible with all 4G/3G/2.5G communication network, make more options for clients’ project construction. The speed of transmission increase 5 times than former terminal, which enable the big data faster.
	Save the Data Flow Support multiple trigger ways, including SMS, ring, and serial port data trigger online or offline mode, can reduce the power consumption effectively and avoid the waste of data flow consumption.
	SMS Backup When online wireless network signal or center network fail to work, it can automatic switch into GSM and to send or receive data (data and SMS are back-up for each other, switch freely).
	Providing much more safer deployment plans, data transmission reaching financial level Four-Faith data terminal supports APN/VPDN private network. Add an encryption form data transmission base on private network, to completely ensure the security of transaction and management data.
	Remote configuration, upgrade and maintenance, greatly improve management efficiency All Four-Faith communication terminals can connect Four-Faith matched remote control platform , and to centralize monitoring, configuration, upgrade, diagnosis, maintenance and control a large number of different areas devices. Help all parties include operator, integrator, device suppliers, etc., to reduce the maintenance cost greatly and also improve management efficiency.

Specification

F2X16 IP MODEM Cellular Specification

Item	Content
Cellular Module	Industrial cellular module
Standard and Band	UMTS/WCDMA/HSDPA/HSUPA 850/1900/2100MHz, 850/900/1900/2100MHz(optional) GSM850/900/1800/1900MHz WCDMA/HSDPA/HSUPA/EDGE CLASS 12
Bandwidth	HSDPA:7.2Mbps(DL),HSUPA:5.76Mbps(UL) UMTS:384Kbps (DL), 384Kbps (UL)
TX power	<24dBm
RX sensitivity	<-109dBm

Hardware System

Item	Content
CPU	Industrial 32 bits CPU
FLASH	512KB (Extendable)
SRAM	256KB

Interface Type

Item	Content
Serial	2 RS232 port and 1 RS485(orRS422) port, 15KV ESD protection Data bits: 5, 6 ,7, 8 Stop bits: 1, 1.5, 2 Parity: none, even, odd, space, mark Baud rate: 110~230400 bps
Indicator	"Power", "ACT", "Online"
Antenna	Standard SMA female interface, 50 ohm, lighting protection(optional)
SIM/UIM	Standard 3V/1.8V user card interface, 15KV ESD protection
Power	Terminal block interface, reverse-voltage and overvoltage protection

Power Input

Item	Content
Standard Power	DC 12V/0.5A
Power Range	DC 5~36V

Power Consumption

Working States	Power Consumption
Communication	95~165mA@12VDC 205~365mA@5VDC
Standby	40~50mA@12VDC 80~100mA@5VDC
Sleep	5mA@12VDC 6mA@5VDC

Physical Characteristics

Item	Content
Housing	Iron, providing IP30 protection
Dimensions	91x58.5x22 mm
Weight	205g

Environmental Limits

Item	Content
Operating Temperature	-35~+75ºC (-22~+167℉)
Storage Temperature	-40~+85ºC (-40~+185℉)
Operating Humidity	95% ( unfreezing)

Download

Specification

F2X16 3G 4G IP MODEM TECHNICAL SPECIFICATION.ZIP

Use Manual

F2X16 Series IP MODEM USER MANUALV1.0.0

Ordering information

Model	Type
F2116	GPRS IP MODEM(GPRS DTU)
F2216	CDMA IP MODEM (CDMA DTU)
F2416	WCDMA IP MODEM (WCDMA DTU)
F2616	EVDO IP MODEM (3G DTU)
F2716	TDD-LTE IP MODEM (4G DTU)
F2816	FDD-LTE IP MODEM (4G DTU)
F2A16	LTE IP MODEM
