Miễn phí vận chuyển với đơn hàng từ 10.000.000đModule truyền thông 2 cổng RS-232 Modbus RTU Cimon CM3-SP02ERRC
Serial module
Independent operation by channel with 3rd party protocol RS-232C and RS422/485 channels.
Read and write data through HMI protocol.
Supports HMI protocol for Multi drop (Max. 32units communication available)(RS422/485)
CDMA modem is built in some of serial modules to control far away PLC.(RS232C)
Supports wide range of communication speed (300bps~38400bps)
RS232C/RS422/485 Comm. port can be used as independent channel or linked channel.
Supports 1:1 / 1:N / N:M in case of RS422/485.
Supports Full-Duplex(RS422) and Half-Duplex(RS485).
Supports MODBUS/RTU Master function.
RS422/485 channels are photo coupler insulation to prevent noise.
|
Model |
SP02ERS |
SP02ERR |
SP02ERC |
SP02ERSC |
SP02ERRC |
|
|---|---|---|---|---|---|---|
|
Interface |
RS232C:1CH |
RS232C: 2CH |
RS232C: 1CH |
RS232C:1CH |
RS232C: 2CH |
|
|
Communication method |
Null modem |
O |
O |
O |
O |
O |
|
Cable modem |
O |
O |
O |
O |
O |
|
|
CDMA modem |
O |
O |
O |
O |
O |
|
|
Operation mode |
Protocol |
User defined protocol program |
||||
|
HMI protocol |
CIMON-PLC HMI Protocol |
|||||
|
MODBUS |
Modbus RTU Protocol |
|||||
|
Graphic Loader |
Control PLC through CICON connection function |
|||||
|
ModBus Master |
Communicate to Modbus RTU slave |
|||||
|
Data type |
Data bit |
8 bit |
||||
|
Stop bit |
1 or 2 bit |
|||||
|
Parity |
Even / Odd / None |
|||||
|
Synchronous |
Asynchronous |
|||||
|
Transmission speed(bps) |
300 / 600 / 1200 / 2400 / 4800 / 9600 / 19200 / 38400 |
|||||
|
Insulation method |
RS232C: N/A |
|||||
